Imaging Features
Real-time color Doppler imaging and triplex imaging in update mode (B/PW/Color).
Molecular imaging for perfusion and targeting information.
Comprehensive measurement tools for image analysis with 2-D and 3-D image data.
Connectivity to external devices, such as a laser, a HIFU transducer, or a source for generating radiation force, allows extened capabilities including sonoporation and elasticity imaging.
Adjustable imaging parameters (center frequency, cycle, PRF, TGC, …etc) for each probe to optimize image quality in different applications.
Full line of image adjustments for live viewing and retrospective review.
Virtual Array (Synthetic Aperture Focusing Technique) for improved image resolution and depth of field.
Save static or dynamic data in multiple data formats including raw, jpg, tif, bmp, DICOM, cineloop (up to 1000 frames) and avi.
Specifications :
| Resolution | Up to 30μm |
| Image Modes | B / M / PW / 2D Doppler (color / power) / 3D / Contrast / Elasticity |
| Frequency | PB506e /PB406e Probe: Center Frequency 40MHz (20MHz-60MHz) PB207e Probe: Center Frequency 20MHz (10MHz-30MHz) |
| Field of View | Depth up to 39 mm (20MHz probe) / Width up to 23 mm |
| Advanced Imaging Modes | Virtual array |
| Frame Rate | Up to 190fps (ECG mode) |
| Data Storage Format | SSD 250MB. jpg, avi, bmp, tif, DICOM SFSC/MFSC, RF raw data, cineloop (proprietary format), video capture |
| Platform | Heating/ ECG gating/ Respiration gating Rat table and mouse table available |
| 3D Motor | 0.05 mm scan interval in the scan axis |
| Display | 15-inch XGA touch screen Intuitive TUI for improved workflow |
| Dimension | 360x280x65mm |
| Operation Software | Microsoft Embedded Win7 (English) |
| Power Requirements | External Power Supply: AC Input 100V-240V (50Hz-60Hz) Max. Power consumption: 36 Watts |
| Environment Requirements | Temperature (min-max): -Storage: -20° to +60°C; Operating: 10° to 40°CHumidity: -Storage: 90%; Operating: 80% EMC: CISPR 11:2015 / EN55011:2016 Group 1, Class A |
| Regulation Compliance | EN61326-1:2013 Safety: EN61010-1:2010 Compliant with Euro RoHS, WEEE certification |
